Nanpu Motor is a manufacturer and brand of H7 PMSM Motor(Permanent Magnet Synchronous Motor) in China. This motor adopts reinforced technology, thickens the motor aluminum barrel, thickens the bearings and motor shaft, making it suitable for high-speed and heavy-duty electric tricycles. Currently, this motor is one of Nanpu Motor’s best-selling products, and I believe Nanpu will become your best partner in China.
H7 PMSM Motor is a high-power motor suitable for electric tricycles, rickshaws, and tuks. The power range of this motor is 1500W~2000W, and the rotor height is 60mm~800mm, which can output higher torque and speed. The control method of sine wave ensures smooth start-up.
| Rated Voltage | 48V~72V | Rated Power | 1500W~2000W |
| Peak Torque | 42N.m~49N.m | Rated Speed | 2500rpm~5000rpm |
| Rotor Height | 60mm~80mm | Permanent Magnet Grade | 38H |
| Motor Color | Silver | Motor shaft | 16 Teeth,14 Teeth |
| Thermal Classification | F | Position Sensor | Hall |
| Ingress Protection | S9 | Control Method | Sine Wave, Vector |
| Pole Pairs | 5 |
| Save Temperature Range | -40℃～85℃ |
| Working Temperature Range | Motor -40℃～55℃ |
| Working Humidity Range | 0～95% |
1.Versatile Speed Adjustment
The motor offers the flexibility to adjust its speed according to customer requirements, ensuring optimal performance across diverse operational scenarios. Its large speed ratio and high torque capabilities make it particularly suitable for demanding tasks requiring robust power output.
2.Advanced Temperature Control
Equipped with built-in temperature control, the Nanpu H7 PMSM Motor continuously monitors the motor’s temperature in real-time. This feature not only enhances safety but also incorporates an overheat protection mechanism that significantly reduces the risk of motor burnout, ensuring reliable and long-lasting performance.
3.Enhanced Reliability and Stability
To further elevate the motor’s reliability and stability, the design incorporates larger bearings with improved precision and a thicker drive shaft. This robust construction, coupled with the integrated temperature control system that performs linear intelligent control, effectively prevents motor damage due to excessive heat, drastically lowering the motor’s failure rate.
4.Powerful and Dependable Performance
The combination of its high torque, adjustable speed, and advanced protection mechanisms results in a motor that delivers exceptional power and performance, making it a reliable choice for critical applications where failure is not an option.
In summary, the Nanpu H7 PMSM Motor stands out for its versatility in speed adjustment, advanced temperature control capabilities, enhanced reliability and stability through robust construction, and its powerful yet dependable performance. These advantages position the motor as an ideal solution for a wide range of demanding applications.
Note: The above drawings are for 1800W BLDC Motor and are for reference only. The length of the motor varies depending on the power.The length of the wire can be customized, and the numbering and power rating can be customized…
| Product Picture | Product Name | Specification |
|---|---|---|
|
|
H7 PMSM Motor |
